3PC Clamp Ball Valve with  mountingpad 200PSI

3PC Clamp Ball Valve with mountingpad 200PSI

ss 3PC Clamp Ball Valve With Mounting Pad 200PSI
On Line:
Visit us on Line:
www.prcvalve.com/VR/ENGD
Ask for FREE Catalog
Email: Jane@grandetek.com
DESCRIPTION

Code: QC18C

Description: 3PC Clamp Ball Valve With Mounting Pad 200PSI

Application:Water, Oil, Gas

Features:

* Material: Investment Cast Body CF8M/CF8

* Connection: Clamp

* Pressure:200PSI for 1/4” to 2”

* Size: 1/4”-2”

* Standard:

  Design: API608

  Clamp:ISO2861

  Inspection: API598, EN12266

  100% Tested at 100 PSI (7 Bars) Open & Close Position

* Options:

  Wide Range Of Seat And Seal Materials Available

  Locking lever

Design Advantage:

* Blow-out Proof Stem SS316

* Clamp connection

* Full bore design

* ISO 5211 standard actuator mounting pad

* Stem packing with O-ring and multiple seal

* Extra high cycle life
